Kafer Compika 1005Z Dial Comparator Indicator 0.000050" Resolution
Kafer Compika 1005Z Dial Comparator Indicator 0.000050" Resolution
SKU:1005Z
Kafer 1005Z Dial Comparator Indicator
0.000050" (50uin) Resolution x 0.004" (20-0-20)
0.12" Overtravel
2.44" Bezel
1N Force
8mm Stem Diameter
The Comparator Gauges Compika offer a high degree of security and precision. They are based on a solid and well thought-out construction taking into account the latest technology. They are manufactured by the most up-to-date methods. The following quality features characterize our manufacturing program of Comparator Gauges Compika:
- Their design conforms to the requirements of DIN 879-1. This applies not only to the dimensions but also to permitted spans of error, hysteresis and measuring pressure.
- Effective shockproof system
- Pinions and shafts of the movement are jeweled
- After removal of the safety cap the adjustment screw on top of the case allows simple and safe zero setting of the instrument over the total measuring range.
- A safety cap prevents unintentional turning of the fine adjustment facility.
- Stem and spindle are made of hardened stainless steel.
- The measuring spindles are very sensitive on account of their accurate guides.
- Additional overtravel assists with the insertion of workpieces into the measuring device.
- The clear scale is shadow free.
- The red tolerance markers are easy to recognize and to set.
- On request all our models are available with a reduced pressure of 0.5 N.
Do you need a water protected version? No problem, we can supply it!
We maintain some inventory domestically. In the event we need to import additional quantity to fulfill your order, typical lead time is 3-4wks. Unless the OEM is back-ordered, at which point we would contact you with an update.
